TX6BMW.F

TX6 Separate speakers for recent BMW & Mini, Ø20cm 8" 3-way 150W RMS 4Ω with original connectors, original frames and neodymium magnets

Introduction

The BMW and the Mini might be the best cars in the world, they come with the worst audio system. Good news, the TX6BMW.E is able to correct this issue with ease. Incredible strong woofers, a level of bass you couldn't even imagine, cristal clear and highly musical midranges, fantastic non agressive tweeters, BMW original frames and original connectors to make it easy to install… You'll get all this, and much more in only one box. This is the TX6BMW.E for the old BMW and the old Mini (see list below).

Features

  • Very easy to install thanks to the original BMW frames and the original BMW connectors.
  • There is nothing to cut, drill or solder.
  • There is zero modification on the car.
  • Breathtaking sound quality, largely beyond the original BMW Harman option.
  • The sound quality is amazing when just connected to the original BMW head-unit.
  • The sound quality can be highly improved with the use of an MTX amplifier like the TX480D.
  • High-end speakers equipped with neodymium magnets and treated paper cones.
  • Ultra-flat woofers (only 38mm thick) with reversed motor structure, grilles and protective fabrics to prevent dust in the gap.
  • Comes with tweeter brackets and all necessary passive x-overs.

In the Box

  • 2x woofers
  • 2x midranges
  • 2x tweeters
  • 2x tweeter brackets
  • 2x passive x-overs (on line)

Specifications

  • 3-way separate speakers with 8" woofers, 4" midranges and 1" tweeters
  • Woofers
    - Diameter: 8" (20cm)
    - Magnet: Neodimium
    - Voice Coil Ø: 2“ (50.8mm)
    - Impedance: 4Ω
    - Cone: composite paper
    - Frame: ABS + carbon
  • Midranges
    - Diameter: 4" (10cm)
    - Magnet: Neodymium
    - Voice Coil Ø: 1" (25.4mm)
    - Impedance: 4Ω
    - Cone: composite paper
    - Frame: ABS + fiberglass
  • Tweeters
    - Diameter: 1" (25mm)
    - Magnet: Neodymium
    - Voice Coil Ø: 1“ (25.4mm)
    - Impedance: 4Ω
    - Cone: silk dome
    - Frame: ABS
  • RMS power: 150W
  • Peak power: 450W
  • Sensitivity: 94.0dB/2.83v/1m
  • Impedance: 4Ω
  • Response: 22Hz - 25000Hz

Compatibility list

BMW

  • E90 (3 Series Sedan 2005 > 2011)
  • E91 (3 Series Estate 2005 > 2012)
  • E92 (3 Series Coupe 2006 > 2013)
  • E93 (3 Series Convertible 2005 > 2013)
  • F06 (6 Series Gran Coupe 2012 > 2018)
  • F12 (6 Series Convertible 2011 > 2018)
  • F13 (6 Series Coupé 2011 > 2018)
  • F20 (1 Series 4 doors 2011 > 2019)
  • F21 (1 Series 2 doors 2011 > 2019)
  • F22 (2 Series Coupe 2014 > 2021)
  • F23 (2 Series Convertible 2015 > 2021)
  • F25 (X3 2010 > 2017)
  • F26 (X4 2014 > 2018)
  • F30 (3 Series Sedan 2012 > 2019)
  • F31 (3 Series Touring 2012 > 2019)
  • F32 (4 Series Coupe 2015 > 2020)
  • F33 (4 Series Convertible 2013 > 2020)
  • F34 (3 Series GT 2013 > 2021)
  • F36 (4 Series Gran Coupe 2014 > 2022)
  • F39 (X2 2014 > 2022)
  • F40 (1 Series 4 doors 2019 > 2024)
  • F44 (2 Series Gran Coupe 2019 > 2024)
  • F45 (2 Series Active Tourer 2014 > 2022)
  • F46 (2 Series Gran Tourer 2015 > 2024)
  • F48 (X1 2015 > 2022)
  • F49 (X1 Long 2015 > 2022)
  • F80 (M3 Sedan 2014 > 2018)
  • F82 (M4 Coupe 2014 > 2020)
  • F83 (M3 Convertible 2014 > 2022)
  • F87 (M2 Coupe 2015 > 2024)
  • G01 (X3 2017 > 2024)
  • G02 (X4 2018 > 2024)
  • G05 (X5 2018 > 2024)
  • G06 (X6 2019 > 2024)
  • G11 (7 Series Sedan 2015 > 2022)
  • G12 (7 Series Sedan Long 2015 > 2022)
  • G20 (3 Series Sedan 2018 > 20**)
  • G21 (3 Series Touring 2019 > 20**)
  • G22 (4 Series Coupe 2020 > 20**)
  • G23 (4 Series Convertible 2020 > 20**)
  • G28 (3 Series Sedan Long 2019 > 20**)
  • G30 (5 Series Sedan 2016 > 20**)
  • G31 (5 Series Touring 2017 > 20**)
  • G32 (6 Series GT 2017 > 20**)
  • G80 (M3 Sedan 2022 > 20**)
  • L15 (i8 Roadster 2014 > 2020)

Mini

  • F54 (Mini Clubman 2015 > 2024)
  • F55 (Mini 5 portes 2014 > 2023)
  • F56 (Mini 3 portes 2014 > 2023)
  • F57 (Mini Cabriolet 2016 > 2023)
  • F60 (Mini Countryman 2017 > 2023)

Recommended associations

  • Works very well connected to the original BMW head-unit
  • Works much better connected to separate amplifier like TX480D, TX2275, TX2450, TR275, TR450, RFL4120 (More power, more bass, better musicality).
  • If your car is not equipped with tweeters behind the side mirrors, you'll have to purchase separately the original BMW or Mini pillars with integrated tweeter grills

Warning

MTX wants you to enjoy your hearing for a long time. Excessive exposure to loud volumes can damage your hearing. The United States Department of Labor recommends not exceeding the following recommendations:

  • 90dB: maximum 8 hours / day
  • 92dB: maximum 6 hours / day
  • 95dB: maximum 4 hours / day
  • 97dB: maximum 3 hours / day
  • 100dB: maximum 2 hours / day
  • 102dB: maximum 90 minutes / day
  • 105dB: maximum 60 minutes / day
  • 110dB: maximum 30 minutes / day
  • 115dB: maximum less than 15 minutes / day
  • 120dB: immediate danger, 0 minutes / day

Wiring Diagram on an original head-unit


Wiring Diagram on a 4-channel amp
