MTX TX6BMW picture

TX6BMW.E

TX6 Separate speakers for old BMW & Mini, Ø20cm 8" 3-way 150W RMS 4Ω with original connectors, original frames and neodymium magnets

Introduction

The BMW and the Mini might be the best cars in the world, they come with the worst audio system. Good news, the TX6BMW.E is able to correct this issue with ease. Incredible strong woofers, a level of bass you couldn't even imagine, cristal clear and highly musical midranges, fantastic non agressive tweeters, BMW original frames and original connectors to make it easy to install… You'll get all this, and much more in only one box. This is the TX6BMW.E for the old BMW and the old Mini (see list below).

Features

  • Very easy to install thanks to the original BMW frames and the original BMW connectors.
  • There is nothing to cut, drill or solder.
  • There is zero modification on the car.
  • Breathtaking sound quality, largely beyond the original BMW Harman option.
  • The sound quality is amazing when just connected to the original BMW head-unit.
  • The sound quality can be highly improved with the use of an MTX amplifier like the TX480D.
  • High-end speakers equipped with neodymium magnets and treated paper cones.
  • Ultra-flat woofers (only 38mm thick) with reversed motor structure, grilles and protective fabrics to prevent dust in the gap.
  • Comes with tweeter brackets and all necessary passive x-overs.

Specifications

  • 3-way separate speakers with 8" woofers, 4" midranges and 1" tweeters
  • Woofers
    - Diameter: 8" (20cm)
    - Magnet: Neodimium
    - Voice Coil Ø: 2“ (50.8mm)
    - Impedance: 4Ω
    - Cone: composite paper
    - Frame: ABS + carbon
  • Midranges
    - Diameter: 4" (10cm)
    - Magnet: Neodymium
    - Voice Coil Ø: 1" (25.4mm)
    - Impedance: 4Ω
    - Cone: composite paper
    - Frame: ABS + fiberglass
  • Tweeters
    - Diameter: 1" (25mm)
    - Magnet: Neodymium
    - Voice Coil Ø: 1“ (25.4mm)
    - Impedance: 4Ω
    - Cone: silk dome
    - Frame: ABS
  • RMS power: 150W
  • Peak power: 450W
  • Sensitivity: 94.0dB/2.83v/1m
  • Impedance: 4Ω
  • Response: 22Hz - 25000Hz

In the Box

  • 2x woofers
  • 2x midranges
  • 2x tweeters
  • 2x tweeter brackets
  • 2x passive x-overs (on line)

Compatibility list

BMW

  • E60 (5 Series Sedan 07/2003 > 05/2010)
  • E61 (5 Series Estate 07/2003 > 05/2010)
  • E63 (6 Series Coupe 2003 > 2010)
  • E64 (6 Series 6 Convertibe 2005 > 2010)
  • E65 (7 Series Sedan 2001 > 2008)
  • E66 (7 Series Sedan Long 2001 > 2008)
  • E70 (X5 08/2006 > 08/2013)
  • E71 (X6 2008 > 2014)
  • E81 (1 Series Compact 2004 > 2011)
  • E82 (1 Series Coupe 2004 > 2011)
  • E83 (X3 2003 > 2010)
  • E84 (X1 2009 > 2015)
  • E87 (1 Series Compact 2004 > 2011)
  • E88 (1 Series Convertible 2004 > 2011)
  • E89 (Z4 Cabriolet 2009 > 2016)
  • E90 (3 Series Sedan 2005 > 2011)
  • E91 (3 Series Estate 2005 > 2012)
  • E92 (3 Series Coupe 2006 > 2013)
  • E93 (3 Series Convertible 2005 > 2013)
  • F01 (7 Series Sedan 2008 > 2015)
  • F02 (7 Series Sedan Long 2009 > 2015)
  • F07 (5 Series GT 2009 > 2017)
  • F10 (5 Series Sedan 2010 > 2017)
  • F11 (5 Series Estate 2010 > 2019)

Mini

  • R60 (Countryman 2010 > 2017)
  • R61 (Paceman 2013 > 2017)

Recommended associations

  • Works very well connected to the original BMW head-unit
  • Works much better connected to separate amplifier like TX480D, TX2275, TX2450, TR275, TR450, RFL4120 (More power, more bass, better musicality).
  • If your car is not equipped with tweeters behind the side mirrors, you'll have to purchase separately the original BMW or Mini pillars with integrated tweeter grills

Warning

MTX wants you to enjoy your hearing for a long time. Excessive exposure to loud volumes can damage your hearing. The United States Department of Labor recommends not exceeding the following recommendations:

  • 90dB: maximum 8 hours / day
  • 92dB: maximum 6 hours / day
  • 95dB: maximum 4 hours / day
  • 97dB: maximum 3 hours / day
  • 100dB: maximum 2 hours / day
  • 102dB: maximum 90 minutes / day
  • 105dB: maximum 60 minutes / day
  • 110dB: maximum 30 minutes / day
  • 115dB: maximum less than 15 minutes / day
  • 120dB: immediate danger, 0 minutes / day
